The channel type washing machine is an industrial boot cleaning and disinfection system. It is mainly used in the food and beverage industry to control personal hygiene safety, and provides the greatest safety guarantee for food safety management.
● 304 Stainless steel, integrated with industrial and hygienic standard design;
● Maximum in Safety and Comfort, convenient and efficient in use ;
● Set soles and boots cleaning in one;Split type, can be divided into two parts as needed, can also be combined into a device for use;
Field Applications
◆ Automatic Cleaning & Sanitizing for
◆ Brewery Production Lines
◆ Cold & Aseptic Filling (CAF) Lines
◆ Beverage & Drink Water Production Lines
◆ Poultry & Meat & (Sea) Food Processing Equipment
Maintenance
★ Clean the roller at least once a day. Clean the water tank and discharge the sewage after each shift.
★ Lift the roller cover when removing the roller，Make the support lever clamp slot into the pin on the tank body，as shown in the figure below.
★ Remove the wool roller on the boot top, remove the M10 bolt, grab the wool roller with both hands and pull it out, as shown in the figure below：Disassembly without tools, convenient and quick.
★ Install and disassemble in reverse order.
Supply Voltage | 380 V/customized | Connection Power | 1.58KW |
Supply Frequency | 50 HZ/customized | Net Weight | 400KG |
Control Voltage | 24 V | Room Temperature | Min. +4℃, Max.+40℃ |
Protection Class | IP 67 | Product Size | 3200*1130*1460mm |
G.W. | 530KG | Package Size | 3300*1230*1560mm |
Optional | Sand blasting | Package Material | Plywood |
