● Adopt German BUSCH RA0240D (or German BUSCH RA0100F) vacuum pump, which can extract air 240 m³/hour and the vacuum degree is 0.1 millibar.
● This type of machine is controlled by computer boards with water proof.
● The whole machine is made of type 304 stainless steel, and the thickness of work room and workbench is 5mm.
● Package capacity is 2-5 times per minute.
● The under pumping system is controlled by two-way valve.
● Oil-water separation device, which can protect vacuum pump and increase the shelf life of the products.
● All vacuum tube, sealer and filler plate are made of silicone.
● Customer can choose sealer bar with holes, which can print date of product, commodity code or expire date on external packing.
Item | Parameter |
Vacuum Chamber Dimensions | 920*780*220mm |
Length of the Seal | 800mm*4 |
Width of the Seal | 8mm |
Seal Span | 650mm |
Voltage Standard | 380v /50HZ |
Power | 5 kw |
Dimensions | 1835*910*1060mm |
Vacuum Degree | ≥-0.1 |
Packaging Capacity | 2-5 times/min |
No. | Components | Description | Photos |
1 | Vacuum Chamber | Double chambers work alternately, One chamber vacuum while another load product, Highly improve the packaging efficiency |
|
2 | Computer Control Panel | Computer panel and Time Relay can optional Easy machine control system, Easy to set and check. | |
3 | Sealing Bar | 700mm*4 Can seal the product tightly Improve the sealing of product packaging | |
4 | Vacuum Pump | Vacuum pump imported fromBUSCH,Germany;CHINA BUSCH RA0100F Vacuum Pump / BUSCH RA063 Vacuum Pump / CHINA 100 Pump | |
5 | Material | Stainless steel 304 High strength, Corrosion resistance, Large volume |  |
